Integrated Robotic Buffing Machine Multi Head Abrasive Belt Surface Finishing Center

Integrated Robotic Surface Finishing Center

System Architecture

1. High-Capacity Multi-Axis Robotic Platform: Heavy-Duty Industrial Robotic Manipulator (Payload Range: 200kg - 2300kg)

2. Modular Abrasive Belt Grinding Array: Precision Contact-Wheel Sanding Stations (Configurable 2/4/6-Head Modules)

3. High-Performance Surface Buffing & Mirror Finishing Module: Automated Buffing Unit (Compatible with Sisal & Cotton/Flannel Wheels)

4. Environmental & Safety Containment System: Industrial-Grade Dust-Free Safety Enclosure (HSE Compliant)

KINGSTONE specializes in bespoke surface finishing architectures tailored to the unique geometry and specific Ra/Rz surface quality requirements of each component. Our engineering philosophy is dynamic—we calibrate operational logic and abrasive sequences for every project, ensuring the solution is perfectly optimized for the desired outcome rather than relying on a fixed template.

We deliver comprehensive End-to-End Turnkey Integration, providing a full suite of engineering documentation and design assets, including:

• • Precision Workholding & Fixture Engineering
  • Workpiece Digital Twin (3D CAD) Generation
  • Multi-Perspective Equipment & System Layouts
  • 3D Facility Visualization & Floor-Space Optimization
  • Technical Process Mapping & Operational Schematics

Targeted Applications: Precision Refinement for Large and Small Components

Our robotic finishing cells are specifically engineered to handle the rigorous surface treatment demands of heavy-duty industrial substrates and large-scale automotive components.

Key Application Sectors:

• • Automotive Structural & Aesthetic Components: High-consistency finishing for car door frames (A/B/C pillars), integrated roof rails (luggage racks), and chassis structural members.
  • Architectural & Industrial Hardware: Specialized in large-format metal assemblies requiring multi-stage sisal and high-gloss cloth buffing.

Surface Defect Remediation (Advanced Surface Correction): Our robotic intelligence is calibrated to eliminate complex surface irregularities with micron-level precision, including:

• • Weld Seam Leveling: Seamless removal of structural welding lines.
  • Material Stress Correction: Elimination of stretcher strain (Lüders lines) and surface striations.
  • Abrasive Refinement: Removal of previous stage grit lines and cross-hatch patterns.
  • Tooling Mark Erasure: Elimination of light die marks, scoring, and casting imperfections.

Heavy-Payload Performance: The system features high-rigidity robotic manipulators with scalable payloads ranging from 100kg to 800kg, ensuring zero-vibration stability even when processing massive workpieces at high centrifugal speeds.

Integrated Robotic Buffing Machine

Abrasive Belt Surface Finishing Center

Heavy Duty Robotic Buffing Machine
