CNC Grinding Machine for Deburring and Grinding of Cast Iron Parts
Machine Features
1. This equipment is a mechanical arm type CNC grinding workstation with multiple degrees of freedom, which is flexible and efficient;
2. The workbench adopts an exchangeable rotary workbench and a quick-change tooling design. The workpiece can be loaded and unloaded at the clamping position while the workpiece is being processed, which is safer and more reliable, and can greatly improve production efficiency;
3. The grinding spindle is equipped with a large diamond grinding wheel spindle and a small grinding spindle, which can be automatically switched according to the processing technology. The large diamond grinding wheel spindle is suitable for rapid grinding of large contours, and the small grinding spindle is suitable for grinding small inner holes and inner arc corners, which can meet the grinding needs of different parts;
4. The control system adopts today's advanced numerical control system with stable performance and high control precision;
5. The machine base, column, and mechanical arm have strong structural rigidity, and the machine tool has good stability;
6. Fully enclosed protection design, the outside can be connected to the dust removal pipeline, which can reduce the damage to the human body caused by dust and noise. The clamping station is equipped with a light curtain, which makes the operation safer and more reliable.
Dust Removal Interface
KS will reserve 2 dust collecting holes above the workshop (hole diameters according to customer requirements), customers can connect the interface with their own dust control system.
Specifications:
| Model Specifications |
CJR7550-100 |
| Maximum grinding workpiece size (Diameter φ * Height) |
Φ750*H500mm |
| Workpiece maximum grinding weight |
0-100kg |
| Spindle grinding wheel |
Diamond grinding wheel (T12*φ405mm) |
| Spindle motor |
7.5kw |
| Spindle speed |
10~2000r/min |
| Grinding spindle rotation angle |
0～90° (spindle can be converted from vertical to horizontal from 0 to 90°) |
| Auxiliary shaft speed |
10000~24000r/min |
| Equipment Dimensions (mm) |
3000*3350*2600mm |
| Equipment weight (t) |
6 |
| Workpiece processing form |
Double station rotation, main axis + auxiliary axis |
FAQ
1st Q.How can I choose the most suitable machines ?
A: Please tell me your specifications,we can choose the best model for you,or you can choose the exact model. You can also send us the products drawing,we will choose the most suitable machines for you.
2nd Q. How can we guarantee quality?
A: Always a pre-production sample before mass production; Always final Inspection before shipment.
3rd Q.what's the MOQ?
a:1 set.
4th Q: How to operate and maintain the machine?
A : First, we will provide a professional and detailed USER GUIDE to you with the machine; Second, we will debug the machine in the best status for you;
At last, we also provide abroad technical training service.
5th Q :What’s dimension of your workpiece ?
A : In order to configure suitable size machine for you. we should get your info. We can professionally design as your requirement.
